1. Vectortile Map

When starting a project using the template, the base map is created by initializing the MapLibre instance with a style.json file. Alternatively, the base map can be implemented using a vector tile layer. This method allows for runtime adjustments to the background style without the need to refresh the entire style property of the MapLibre instance.

  1. Comment Out the Style Property: In the src/App.tsx file, comment out the style property within the options attribute of the MapLibreMap component.

    <MapLibreMap
    options={{
    //style: "https://wms.wheregroup.com/tileserver/style/osm-bright.json",
    zoom: 4,
    }}
    style={{ position: "absolute", top: 0, bottom: 0, left: 0, right: 0 }}
    />
  2. Add mapId, center and adjust zoom:

    <MapLibreMap
    mapId="map_1"
    options={{
    zoom: 5,
    center: [10.447683, 51.163361],
    //style: "https://wms.wheregroup.com/tileserver/style/osm-bright.json",
    }}
    style={{ position: "absolute", top: 0, bottom: 0, left: 0, right: 0 }}
    />
  3. Create a New Component File: Establish a new file at src/components/Layers.jsx.

  4. Define a State Variable: Initiate a state variable named bgLayerState as follows:

    import { useState } from "react";
    import { useEffect, useState } from "react";

    export default function Layers() {
    const [bgLayerState, setBgLayerState] = useState({
    url: "https://wms.wheregroup.com/tileserver/tile/tileserver.php?/europe-0-14/index.json?/europe-0-14/{z}/{x}/{y}.pbf",
    layerId: "openmaptiles",
    });

    return <></>;
    }
  5. Fetch Background Style: Utilize a fetch operation within the initialization effect to acquire the background style from the specified URL. And insert the layers property from the fetched style.json into the layers property of the state variable:

    fetch("https://wms.wheregroup.com/tileserver/style/osm-bright.json")
    .then((response) => response.json())
    .then((data) => {
    setBgLayerState((current) => {
    return { ...current, layers: data.layers };
    });
    });
  6. Include the MlVectorTileLayer Component: In the JSX, add the MlVectorTileLayer component. Use the spread operator to pass all properties of the bgLayerState variable as attributes to the component:

    return<>{bgLayerState.layers && <MlVectorTileLayer {...bgLayerState} />;}</>;
  7. Import and Use the New Component: import Layers from "./components/Layers" in src/App.tsx and render it within the application's JSX.
